Specifications

• ENGINE

  add remove
  • Rated output:
    145 hp at 7,750 rpm
  • Engine:
    Standard
  • Engine Type:
    Flat Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    145
  • Horsepower (kW):
    108.2
  • Horsepower RPM:
    7750
  • Torque (Ft Lbs):
    110
  • Torque (Nm):
    149.1
  • Torque RPM:
    6500
  • Cooling:
    Liquid / Air
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (mm):
    106.5
  • Bore (in):
    4.19
  • Stroke (mm):
    73
  • Stroke (in):
    2.87
  • Displacement (cc):
    1300
  • Displacement (ci):
    79.3
  • Turbocharged:
    No
  • Supercharged:
    No
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Premium
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Type:
    Air/liquid-cooled four-stroke flat twin engine with double overhead and chain driven camshafts (BMW ShiftCam)
  • Bore / stroke:
    106.5 mm x 73 mm
  • Capacity:
    1,300 cc
  • Max. torque:
    110 lb-ft at 6,500 rpm
  • Compression ratio:
    13.3 : 1
  • Mixture control:
    Electronic intake pipe injection
• PERFORMANCE / FUEL CONSUMPTION

  add remove
  • Maximum speed:
    over 120 mph
  • Fuel type:
    Super unleaded (max. 15% ethanol, E15), 95 ROZ/RON, 90 AKI
• POWER TRANSMISSION

  add remove
  • Gearbox:
    Constant-mesh 6-speed gearbox integrated in the transmission housing
  • Drive:
    Cardan shaft drive
  • Traction control:
    BMW Motorrad DTC
• CHASSIS / SUSPENSION / BRAKES

  add remove
  • Frame:
    Two-part frame consisting of main frame, bolted rear frame, and load-bearing engine
  • Suspension travel, front / rear:
    8.3" / 8.7"
  • Front wheel location / suspension:
    BMW Motorrad EVO-Telelever, handlebar tilting decoupled via flex element, central DSA shock absorber
  • Rear wheel location / suspension:
    BMW Motorrad EVO-Paralever, cast aluminum single-sided swingarm, transversal connected swing arm bearings, central DSA spring strut, load compensation
  • Wheelbase:
    60.4 in
  • Castor:
    4.67"
  • Steering head angle:
    63.8 °
  • Wheels:
    Cross spoke wheels
  • Rim, front:
    3.00 x 19“
  • Rim, rear:
    4.50 x 17“
  • Tyre, front:
    120/70 R19
  • Tyre, rear:
    170/60 R17
  • Brake, front:
    Twin disc brake, semi-floating brake discs, diameter 310 mm, 4-piston radial brake caliper
  • Brake, rear:
    Single disc brake, bolted to the disc rim, diameter 285 mm, 2-piston floating caliper
  • ABS:
    BMW Motorrad Full Integral ABS Pro (lean angle optimized)
• DIMENSIONS / WEIGHTS

  add remove
  • Usable tank volume:
    9.2 gal
  • Reserve:
    approx. 4.5 l
  • Unladen weight, road ready, fully fuelled:
    593 lbs ¹⁾
  • Max. permitted weight:
    1,069 lbs
  • Payload (with standard equipment):
    478 lbs
  • Max. load (with standard equipment):
    268.9802754
  • Length:
    89.8 in
  • Seat height, unladen:
    34.25" / 35.0"
  • Height (over windscreen, with DIN unladen weight):
    62.5"
  • Width:
    39.8"
  • Inner leg curve at unladen weight:
    72.4" / 77.9"
• EQUIPMENT

  add remove
  • Standard equipment:
    Heated grips, Cruise control DCC, Tire Pressure Monitor, Keyless Ride, Extended hand protector with integral turn signal, Additional headlight, Electronic suspension DAS with load compensation & Various attachment options for accessories
  • Optional equipment:
    Adaptive vehicle height control, Automated Shift Assistant, Riding Assistant with radar sensors, Forged enduro wheels, Enduro package Pro, Topcase carrier with electrical interface, Comfort handlebars & Double silencer
  • Optional accessories:
    Aluminum case, Volume expansion for aluminum case, Aluminum topcase with electrical interface, Luggage plate, passenger seat, Tank bag, Various luggage bags, Headlight guard & Spoiler add-on for windscreen
