Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Displacement (cc):
    567
  • Horsepower (bhp):
    44
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / AWD
  • Number Of Driveline Modes:
    2
  • Rear Unlocking Differential:
    Yes
  • Driveline Brand:
    On-Demand™
  • Limited Slip Differential Location:
    Center
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (mm):
    2790
  • Width (in):
    58
  • Height (in):
    73
  • Wheelbase (in):
    73
  • Ground Clearance (in):
    10
  • Dry Weight (lbs):
    1073
  • Payload Capacity (lbs):
    1000
  • Towing Capacity (lbs):
    1500
  • Fuel Capacity (gal):
    9
  • Engine Displacement to Weight (cc):
    0.53
• STEERING

  add remove
  • Steering Control:
    Steering Wheel
  • Steering Type:
    Manual
• SUSPENSION

  add remove
  • Front Suspension Type:
    McPherson Strut
  • Front Travel (in):
    9
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Travel (in):
    10
  • Number Rear Shock Absorbers:
    2
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Front Tire (Full Spec):
    Carlisle 489: 25 x 8-12
  • Rear Tire (Full Spec):
    Carlisle 489: 25 x 10-12
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
• STORAGE

  add remove
  • Bed Length (in):
    32
  • Bed Width (in):
    42
  • Bed Height (in):
    11.5
  • Bed Capacity (lbs.):
    500
  • Bed Volume (m3):
    0.3
  • Cargo Bed Tilt:
    Yes
• INSTRUMENTATION

  add remove
  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Gauge
