Specifications

• ENGINE

  add remove
  • Engine Type:
    286cc liquid-cooled 20º single-cylinder four-stroke
  • Bore And Stroke:
    76mm x 63mm
  • Induction:
    Fuel injection w/ 38mm throttle body
  • Ignition:
    Full transistorized
  • Compression Ratio:
    10.7:1
  • Valve Train:
    DOHC; four valves per cylinder
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    41mm telescopic fork; 5.1 inches of travel
  • Rear Suspension:
    Pro-Link® single shock; 4.2 inches of travel
  • Front Brake:
    Single 296mm disc
  • Rear Brake:
    Single 220mm disc
  • Front Tire:
    110/70-17
  • Rear Tire:
    150/60-17
• Dimensions

  add remove
  • Rake:
    24.70°
  • Trail:
    93mm (3.7 inches)
  • Wheelbase:
    53.3 inches
  • Seat Height:
    31.5 inches
  • Curb Weight:
    313 pounds - Includes all standard equipment, required fluids and full tank of fuel—ready to ride.
  • Fuel Capacity:
    2.7 gallons
• Other

  add remove
  • Emissions:
    Meets current EPA standards; Models sold in California meet current CARB standards and may differ slightly due to emissions equipment
• Factory Warranty Information

  add remove
  • Warranty:
    Transferable, unlimited-mileage limited warranty
