Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Bore (in):
    3.82
  • Stroke (in):
    4.45
  • Displacement (cc):
    1670
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Compression ratio:
    8.36:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Belt
  • Gear Ratio (1):
    2.375
  • Gear Ratio (2):
    1.579
  • Gear Ratio (3):
    1.16
  • Gear Ratio (4):
    0.935
  • Gear Ratio (5):
    0.8
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    93.9
  • Width (in):
    36.8
  • Height (in):
    44.1
  • Wheelbase (in):
    65.6
  • Ground Clearance (in):
    6.1
  • Dry Weight (lbs):
    612
  • Fuel Capacity (gal):
    4
  • Engine Displacement to Weight (cc):
    2.73
  • Turning Radius (ft):
    11
  • Fuel Capacity Reserve (gal):
    0.9
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.3
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    4.3
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Kabaya
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Front Tire (Full Spec):
    120/70 ZR18
  • Front Wheel Width (in):
    3
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    11.1
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    28.1
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Standard
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Standard
