Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    3
  • Valves Per Cylinder:
    3
  • Valve Configuration:
    SOHC
  • Bore (in):
    1.5
  • Stroke (in):
    1.71
  • Displacement (cc):
    49
  • Carburetion Brand:
    Mikuni
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Compression ratio:
    12.0:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    73
  • Width (in):
    27
  • Height (in):
    41.1
  • Wheelbase (in):
    50.4
  • Ground Clearance (in):
    4.5
  • Dry Weight (lbs):
    187
  • Fuel Capacity (gal):
    1.2
  • Engine Displacement to Weight (cc):
    0.26
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Travel (in):
    2.3
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    2.2
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Front Tire (Full Spec):
    120/90 R10
• BRAKES

  add remove
  • Front Brake Type:
    Drum
  • Front Brake Diameter (in):
    4.3
  • Rear Brake Type:
    Drum
  • Rear Brake Diameter (in):
    4.3
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    29
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Standard
